Zephyr – 21 inches – Externally Vented – Range Hood Insert – stainless steel

The Tornado Mini ENERGY STAR power pack is designed with energy efficiency and versatility in mind. This ENERGY STAR-certified insert has a small footprint that fits under the standard 12 cabinet depth or choose one of our optional, adjustable-depth, stainless steel liners to accommodate custom hood enclosures from 17-1/2 to 20-1/2 deep. Features include dual-level LumiLight LED lights and an ultra-quiet 290-CFM blower controlled by 3-speed mechanical slide controls.

Specifications

Key Specs

• Color Finish: Silver
• Product Height: 9 2/3 inches
• Product Width: 20 5/9 inches
• Product Depth: 11 inches
• Exhaust Vent Location: Top
• Vent Type: Ducted
• Vent Style: External

General

• Brand: Zephyr
• Model Number: AK8400BS-ES
• Product Name: Tornado Mini Energy Star 21 in. 290 CFM Insert Range Hood

Dimensions

• Minimum Installation Height Above Cooktop: 20 inches
• Maximum Installation Height Above Cooktop: 36 inches
• Standardized Width: 21 inches
• Product Weight: 14 pounds
• Duct Shape: Round

Cut-Out Dimensions

• Cut-Out Width: 19 3/4 inches
• Cut-Out Depth: 10 1/4 inches

Features

• Range Hood Type: Insert
• Number of Fan Speeds: 3
• Temperature Sensor: No
• Control Type: Slide
• Delay Shut-Off: No
• Auto Fan Shut-Off: No
• Remote Control: No
• Damper Included: No
• Integrated Light(s): Yes
• Number of Lights: 2
• Number of Light Levels: 2
• Maximum Bulb Wattage: 6 watts

Performance

• Maximum Air Flow Capacity: 290 cubic feet per minute
• Minimum Air Flow Capacity: 180 cubic feet per minute
• Maximum Operating Sound Level: 3.2 sones
• Minimum Operating Sound Level: 1.3 sones

Filter Info

• Filter Material: Mesh
• Dishwasher-Safe Filter: Yes
• Removable Grease Filter: Yes
• Number of Filters: 1

Electrical Specification

• Amperage: 2 amperes
• Voltage: 120 volts

Specifications

• UPC: 646328011597
